Blundell Pipes and Tubes, located in Hamilton, New Zealand, is a trusted name in the manufacturing and supply of top-notch Titanium Seamless Tubing, specifically designed for critical and high-performance industrial applications. This tubing is crafted without any welded joints, ensuring it boasts superior dimensional uniformity, enhanced pressure resistance, and remarkable structural integrity. Thanks to cutting-edge production methods and rigorous quality control, Blundell Pipes and Tubes consistently provides tubing that meets international standards. The company caters to a variety of industries, including chemical processing, power generation, marine, aerospace, and medical engineering, offering tailored titanium seamless tubing solutions that promise long service life, outstanding performance, and reliable operation in even the most demanding environments around the globe.
The Titanium Seamless Tubing is made from commercially pure titanium and popular alloys like Grade 1, Grade 2, and Grade 5 (Ti-6Al-4V). These materials deliver an impressive mix of low density, high strength, and exceptional resistance to corrosion and oxidation. Typical mechanical properties include tensile strength ranging from 345 to 950 MPa and yield strength between 275 and 880 MPa, depending on the grade. Additionally, the tubing showcases excellent elongation, fatigue resistance, and creep strength, making it ideal for high-pressure, high-temperature, and dynamically loaded service conditions.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance
| Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or bevelled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing
| A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Seamless Tubing from Blundell Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Blundell Pipes and Tubes, a leading supplier of Titanium Seamless Tubing in Hamilton, New Zealand, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Blundell Pipes and Tubes, we provide custom sizes of Titanium Seamless Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Titanium Seamless Tubing finds its place in industries that require high purity, strength, and corrosion resistance. In chemical and petrochemical plants, it’s utilized for heat exchangers, condenser tubes, and fluid transfer systems that handle aggressive media. The marine and offshore sectors depend on it for seawater cooling and hydraulic systems. In power generation, it plays a crucial role in condenser and cooling circuits. Furthermore, aerospace, medical equipment, oil and gas, and advanced engineering industries also rely on it for its lightweight strength, low maintenance requirements, and exceptional reliability in safety-critical applications.
